This article explains the role and design technology of Analog ASICs in authentication devices. It introduces key points in detail for meeting the latest security requirements, such as ensuring signal accuracy, power saving, and utilizing PUF.
The Role of Analog ASICs in Authentication Devices
In authentication devices, analog ASICs are a core component for accurately and stably processing signals from sensors. In applications such as biometric authentication and physical token authentication, it is necessary to acquire analog signals—such as fingerprints, veins, or voltage changes—with high precision and bridge them to the subsequent digital authentication processing. Low noise and power saving, which are difficult to achieve with a combination of general-purpose ICs, can be realized by application-specific analog ASICs. Highly integrated design allows for both miniaturization and high reliability, enabling a high security level to be maintained even in edge applications.
Representative Examples and System Configuration of Authentication Devices
Authentication devices have diverse applications, including biometric authentication equipment, access control systems, and security modules for IoT. All of them require high-precision input signal processing and fraud detection. For this purpose, they utilize a system configuration integrating sensors, amplifiers, filters, A/D conversion circuits, and authentication logic. The front-end section that handles analog signals is the key element that determines the authentication accuracy and responsiveness of the entire system, and this is where the specialized design technology of analog ASICs is utilized.
Main Circuit Functions Carried by Analog ASICs
Analog ASICs can integrate diverse functions such as amplification circuits and filtering circuits, A/D conversion circuits, which are the starting points of signal processing, as well as temperature compensation and reference power supply circuits. These circuits are optimized to stably handle minute signals from external sensors and significantly influence the system’s sensitivity and security accuracy. Furthermore, by adding product-specific operating characteristics, they also fulfill the role of individual identification functions for authentication and acting as a trust anchor. Such integrated circuits enable overall performance enhancement and differentiation of the design.
Comparison with Discrete Configuration and Benefits of Integration
In a discrete configuration, signal processing is realized by combining multiple analog ICs and passive components. This results in design load factors such as increased complexity of board design, more noise sources, and increased trimming effort. In contrast, analog ASICs integrate the necessary circuits onto a single chip, making it possible to improve the matching accuracy between circuits and enable a design optimized in terms of both area and power consumption. Moreover, specialized design for specific applications allows for the reduction in the number of components and improvement in reliability, which is advantageous from the perspective of manufacturing cost and quality control.
Analog ASIC Design Process and Technical Key Points
The analog ASIC design process begins with defining specifications to achieve optimal characteristics for each application, proceeding through topology selection, circuit design, layout, and verification before reaching manufacturing. Especially for authentication applications, signal integrity and reproducibility, environmental resistance, and minimizing differences between products are crucial. Since general IP reuse is often difficult, circuit configurations are frequently designed individually. This demands close cooperation between circuit design at the transistor level and physical layout, making design judgment backed by experience indispensable.
Formulation of Design Specifications and Selection of Elemental Technologies
The design specification begins with clearly defining the required accuracy, operating voltage, temperature range, bandwidth, and noise tolerance of the target authentication device. Following this, necessary circuit blocks (amplifier, ADC, reference voltage, power management, etc.) are identified, and the architecture is selected based on their respective performance requirements. Particularly for security applications, circuits that show consistent performance even against power supply fluctuations and temperature changes are required, making the introduction of variation control technology and offset cancellation technology important.
Noise and Interference Countermeasures in Layout Design
In layout design, noise suppression technology is indispensable to prevent performance degradation caused by crosstalk, parasitic elements, power supply ripple, and so on. Analog circuits are more sensitive than digital circuits, and physical structures such as GND impedance, wiring length, and opposing area affect operation, requiring a careful floor plan. Furthermore, for security applications, countermeasures against information leakage at the layout level (e.g., differential signaling or side-channel resistance design) are also crucial design elements from the perspective of physical attack resistance.
Challenges in the Verification Phase and Utilization of Measurement Technology
After design completion, operation confirmation is performed through simulation and silicon evaluation. However, the operating point of analog circuits tends to change easily depending on the environment and manufacturing lot, and results often deviate from theoretical predictions. Therefore, in the verification phase, corner simulation, Monte Carlo analysis, and temperature/voltage variation tests using actual devices become important. High-precision probing technology and automated measurement systems are utilized for measurement, aiming to shorten the development period and improve the accuracy of design feedback.
Hardware Authentication Technology Using Analog Signals
In hardware-based authentication technology, physical identification methods utilizing individual differences in analog signals or natural noise are attracting attention. These technologies have higher clone resistance compared to conventional digital authentication. Methods such as PUF (Physically Unclonable Function) and analog scrambling are being put into practical use. Analog ASICs are the ideal platform for integrating these functions with high precision and low power consumption. In authentication based on sensor signals, the performance of separating noise and signals is crucial, requiring advanced knowledge of analog design.
Design and Application using PUF
PUF is a mechanism that generates unique identification information using the variations on the silicon or natural differences in circuit characteristics. This technology is used as a device-specific fingerprint, realizing a highly secure authentication method that does not require the storage of secret keys. In analog ASICs, bias control and compensation techniques are important for intentionally incorporating circuit variations into the design to obtain stable PUF responses. PUF has widespread applications, including token authentication, secure boot of IoT devices, and tamper detection.
Tamper Prevention Methods Using Analog Scramble Signals
Analog scrambling is a technique that makes unauthorized reading or tampering from the outside difficult by adding specific modulation or randomization processing to the sensor output signal. This method achieves high security because the input signal possesses irreproducible randomness and generates unpredictable responses. Analog ASICs can implement this processing in real-time, strengthening security without compromising authentication accuracy. The design closely involves modulation circuits, random number generators, and decoding logic.
Identification Technology Utilizing Individual Differences in Sensor Response
Sensor devices have slightly different response characteristics, even within the same part number, due to manufacturing variations and material properties. While these differences are usually treated as variations, they can conversely be used as identification information in authentication applications. Designs are progressing that use features such as response characteristics at specific frequencies, voltage response during temperature changes, and capacitance fluctuations for individual authentication and verification of authenticity. Analog ASICs provide the optimal components for detecting and processing these individual differences.
Future Outlook for Security-Compliant Design
As security technology evolves, the design requirements for analog ASICs are becoming more advanced and diverse. Particularly in authentication functions within the fields of IoT and edge computing, power efficiency, real-time processing capability, and resistance to external attacks are required simultaneously. Analog ASICs are expected to increase in importance as a means of providing high design flexibility and circuit optimization to meet these complex requirements. The compatibility between flexible custom design and mass production capability will be the key to future product competitiveness.
Design Balancing Low Power Consumption and High Security
Security functions usually require continuous operation or continuous monitoring, making increased power consumption a design challenge. Especially in battery-powered edge devices and wearable devices, it is required to maintain a robust authentication process while achieving operation below the milliwatt level. Analog ASICs can meet these requirements by introducing dedicated power control circuits and low-power architectures. Designs equipped with secure standby modes and on-demand authentication functions are expected to become the mainstream.
Circuit Flexibility to Support Diverse Authentication Methods
In recent years, various authentication methods—such as biometric authentication, cryptographic tokens, PUF, and physical trust-based methods—coexist, and the combined use of multiple methods is advancing. Analog ASICs require high configuration flexibility and expandability. For example, architectures that can accommodate multiple specifications during the design stage, such as changing the type of sensor input, adjusting the filter bandwidth, and varying the output format, are demanded. Flexible multi-modal support is precisely what differentiates the design capabilities of next-generation authentication equipment.
Inheritance of Analog Design and Challenges in Engineer Training
Analog ASIC design is a field requiring advanced analog circuit theory and practical layout technology, and it faces the challenge of containing many individual-dependent elements supported by years of experience. Training young engineers has become difficult, making the inheritance and standardization of design know-how and the sophistication of design support tools urgent tasks. The utilization of model-based design and AI-supported layout technology is beginning. Introducing these will reduce dependence on individual expertise and establish highly reproducible design flows, which will contribute to future competitiveness.
Conclusion
Analog ASICs are an extremely important element for simultaneously achieving high performance, miniaturization, and low power consumption in authentication devices. Particularly in the security field, defense capabilities at the circuit level and signal consistency determine the safety of the entire system. Designers are required to enhance their ability to handle diverse authentication technologies and aim for smarter and more robust analog design.
The Significance of Analog ASIC Design in Authentication Devices
In authentication devices, analog ASICs are a critical presence that handles the signal processing—the core of security—at the physical layer. They realize diverse processing such as acquisition of minute signals from sensors, removal of disturbances, and characteristic extraction for individual identification, all with low power consumption and high precision. Reliable integrated design enables device miniaturization and high integration, expanding the range of applications to mobile terminals and edge nodes. Appropriate design and utilization of analog ASICs lead to improved competitiveness for authentication equipment overall.
Technical Key Points and Implementation Points in the Design Field
When designing analog ASICs, it is necessary to proceed systematically and consistently with elements such as specification clarification, optimal selection of circuit blocks, noise countermeasures, layout strategy, and verification using actual devices. For authentication applications, elements such as tamper resistance for security functions and the stability of PUF responses must be considered from the initial design stages. In implementation, ensuring reproducible operating characteristics and the ability to handle manufacturing variations are crucial. Systematic design based on these considerations is the key to success.
What is the Design Capability Required to Meet Future Security Demand
As authentication functions become required in various fields such as IoT, mobile, and industrial equipment, analog ASICs will demand more sophisticated and flexible designs. Designers need a comprehensive design perspective that considers not just the optimization of circuit operation but also the security level and operating environment. Understanding and introducing new technologies like PUF and analog scrambling and establishing efficient development systems through the utilization of design tools and human resources, will be key differentiators in future authentication device design.
