Low-Power SRAM Characteristics and Design Considerations – Impact of Leakage Current and Standby Power on Design
This article explains the mechanisms that enable high-speed operation in SRAM and the factors that generate standby power due to leakage current. Furthermore, it compares the characteristics of SRAM with those of non-volatile memories such as flash, MRAM, and FeRAM (FRAM, ferroelectric memory), and presents an approach to selecting the optimal memory for minimizing device power consumption.
Basic Characteristics and Power Consumption Mechanisms of Low-Power SRAM
SRAM is a volatile memory technology that provides high-speed random access and is widely
used in microcontroller-based and other embedded systems. In recent years, with the widespread use of battery-powered devices, the importance of low-power SRAM has increased. SRAM power consumption is mainly composed of active operation power and standby power, and understanding the mechanisms of each is crucial in system design.
SRAM Operating Principle and Factors Generating Dynamic (Active) Power
SRAM typically stores data in six-transistor (6T) cells. Because data can be stably held using flip-flop circuits, it is characterized by extremely high read speed. On the other hand, reading and writing data requires driving bit lines and word lines, and this operation consumes dynamic power. In particular, in higher-capacity SRAMs, power consumption due to charging and discharging of bit lines becomes a significant factor. Therefore, in recent years, efforts have been made to reduce dynamic power through circuit design and power management techniques.
Relationship Between Standby Current and Leakage Current
Since SRAM is a volatile memory, it must continuously consume current to retain stored data while power is applied.
. This ongoing draw is the standby current. The main factor in standby current is transistor leakage current, which is a small current that flows even when the transistor is completely off. As process scaling progresses, the gate length of transistors shortens, and the impact of leakage current tends to become relatively larger. As a result, the proportion of standby current in the overall system power consumption may increase.
Reducing Power Consumption through Low-Voltage Operation and Process Scaling
To achieve low-power SRAM, technologies such as reducing supply voltage and optimizing circuit architecture are important. Lowering the supply voltage can significantly reduce dynamic power consumption; however, it also introduces challenges such as reduced noise margin and potential impacts on operational stability. In addition, while process scaling enables smaller cell area and higher capacity, it also introduces a new challenge: increased leakage current. Therefore, low-power SRAM design requires balancing power consumption and operational stability through a combination of circuit design, power management, and process technology.
Design Optimization: How SRAM Compares with Other Memory Technologies
In memory selection, it is important to comprehensively evaluate multiple factors, such as capacity, power consumption, rewrite endurance, and access speed, rather than just a single characteristic. SRAM excels in high speed, but as a volatile memory it draws standby power. Non-volatile memory, on the other hand, retains data even when the power is removed. Since the most suitable memory varies depending on the system’s application and operating conditions, it is necessary to consider design optimization after understanding the technical characteristics of each.
Flash Memory: High Density and Low Cost
Flash memory is a non-volatile memory that stores information by accumulating charge in an insulating layer, and it lends itself to high-density integration. Because the cell structure can be made small, it enables large-capacity memory at relatively low cost, which is why it is widely used in storage applications. On the other hand, it requires high voltage during write and erase operations, which can impose constraints on write time and power consumption. In addition, since writes rely on a tunnel-oxide mechanism, there is a finite limit on program/erase (P/E) cycles, and for applications requiring frequent updates, endurance must be considered in system design.
High-Speed Operation and Non-Volatility: MRAM and ReRAM
MRAM and ReRAM are next-generation non-volatile memories that utilize physical phenomena different from conventional memory technologies, and both are advancing from research toward commercial deployment. MRAM stores data using magnetic tunnel junctions (MTJs) and is characterized by achieving relatively high-speed access performance while maintaining non-volatility. ReRAM, on the other hand, stores data by using resistive switching, and its simple cell structure is expected to enable high integration density. These memories have drawn interest as technologies approaching SRAM-class speed; however, evaluation is required based on application suitability, cost, and compatibility with manufacturing processes.
FeRAM: Combining Low Power Consumption, High-Speed Writing, and High Endurance
FeRAM is a non-volatile memory that records data using ferroelectric materials. Because it retains information through polarization states rather than charge accumulation, write operations are fast and low-power. It is also valued for its high rewrite endurance, which allows for long-term use even in applications where frequent data updates occur. Furthermore, because it is non-volatile, it can retain data even when the power is removed, eliminating the need for standby power. Therefore, it is sometimes considered for use in systems that require both low power consumption and high-speed writes, such as sensor nodes and IoT devices.
Optimal Memory Selection Based on Memory Characteristics
In electronic device design, it is necessary to comprehensively consider not only memory performance but also characteristics such as power consumption, data retention method, and rewrite endurance. While SRAM is widely used in applications requiring high-speed access, standby power consumption and data retention mechanisms can affect system design. It is important to consider the optimal memory configuration by comparing multiple memory technologies, taking into account the application’s operating conditions and data update frequency.
Applications Suitable for Low-Power SRAM
SRAM offers extremely high read/write speeds and excellent random access performance, making it widely used in processor cache memory and high-speed buffer applications. Its simple write operation also keeps access latency low, making it well suited to real-time processing. Low-power SRAM is designed to reduce standby current compared to conventional types and is used in embedded devices and industrial equipment. However, because it is a volatile memory that requires continuous power to retain data, system design that considers standby power consumption and data retention mechanisms is crucial.
Design Conditions Where Non-Volatile Memory is Effective
Non-volatile memory is considered in systems that must retain data even when power is lost. For example, it is effective in environments where power loss may occur, such as sensor-log storage or configuration-data retention. In addition, in devices with long standby periods, using non-volatile memory that does not require standby current can help reduce overall system power consumption. Multiple technologies such as flash, MRAM, and FeRAM exist, each with different characteristics in terms of capacity, write speed, and rewrite endurance; therefore, selection must be made according to the application requirements.
Memory Selection from a System-Level Perspective
When selecting memory, it is important to evaluate not only a single performance metric but also the operating conditions of the entire system. For example, if high-speed access is the top priority, SRAM may be suitable, but in terms of power consumption and data retention, non-volatile memory may be advantageous. Factors such as data update frequency, operating temperature, and product lifetime also influence memory selection. Understanding the characteristics of multiple memory technologies and considering configurations that leverage their respective strengths is the foundation of a robust system design.
